    Al Mylar Cat5e Ethernet Lan Cable HDPE Bare Copper PVC PE Utp Cat5e Cable

    Description:

    1, LANSAN Intelligent Structure Cabling products.

    2. Cat5e UTP 24AWG are made in flexible stranded conductor, applicable to network.

    3, Constructed with high-quality cable during installation and provides strain-relief.

    4, A variety of colors make the network installation and color-code more easily.

    5, Easy to insert and remove cables in high density applications.

    6, Lots of successful project cases in worldwide finance, government buildings and other industries.


    Specification:

    ITEMCAT5E UTP
    No. of Conductor4 Pairs
    ConductorMaterialBare Copper Solid
    Construction7 / 0.20± 0.006 mm
    InsulationMaterialPolyethylene
    Thickness0.20mm
    Diameter0.91 ±0.05mm
    Inner LayerDirectionS
    Pitch REF30mm underneath
    Outside LayerDirectionS
    Pitch REF90±10mm
    Rip CordMaterialNylon
    JacketMaterialLSZH
    Thickness0.55mm
    Diameter5.1 ± 0.2 mm
    ColorOptional
    MarkingOptional
    ELECTRICAL PROPERTIES
    ITEM
    Insulation ResistanceMin. 5000 mega ohms-km at 20℃
    Dielectric Test1000V DC /1 min ; No Breakdown
    Temperature Rating60℃
    Voltage Rating30V

    Features:

    1,Independently tested and verified by ETL

    2,Humanized Design

    3,Separated structure inside the cable ensures the stable transmission of data.
