1U Rack 19 Inch 568A & 568B 24 Port RJ45 Cat5e UTP Patch Panel
DESCRIPTION
UTP Cat5e 24 ports patch panel with quick tool design allows
installer to install in the most efficient way
It is compatible with full series keystone Jack, included normal
type and quick tool type
Combined with UTP LAN cable, Patch cords, and Keystone jack, it
provide excellent compatible performance and extra DB value for
full series cabling system
FEATURES
* Quick installation design
* Full series keystone Jack supported
* Back Frame for management
SPECIFICATION
Electrical:
1.Voltage rating: 125 VAC RMS
2.Current rating: 1.5 AMP
3.Contact resistance: 100 milliohms Max
4 .Insulation resistance: 1000 megohms Min @ 500 DC
5. Dielectric strength: 750 vac rms 60hz,1m Min
Environmental:
1. Storage: -40° to + 70°
2. Operation: -10° to + 60°
Conform to tia/eia 568b category 5e
Mates with modular plug conforming to FCC part 68
Mechanical:
1.Housing material : PBT+15%GF UL94V-0
2.Panel frame: powder coating in black color
3.Idc material: pc,terminal:phosphor bronze,tin plating
4.RJ45 jack life: 750 times Min
5.Idc life: 200 times Min
6.Wire: AWG 24~26
7.Tia cat 5e perm. link test: worst pair next margin ≥ 5.0db
8.Retentiveness of insertion structure : 50n 60±5s
Category 5e Characteristic:
| Frequency | Near-end cross talk db. Min | Return loss db. Min | Alternation db. Max |
| 1.0 MHZ | 65.0 | 35.5 | 0.1 |
| 4.0 MHZ | 65.0 | 35.5 | 0.1 |
| 8.0 MHZ | 64.9 | 35.5 | 0.1 |
| 10.0 MHZ | 63 | 35.5 | 0.1 |
| 16.0 MHZ | 58.9 | 35.5 | 0.2 |
| 20.0 MHZ | 57.0 | 34.0 | 0.2 |
| 25.0 MHZ | 56.0 | 32.0 | 0.2 |
| 31.25 MHZ | 53.0 | 30.1 | 0.2 |
| 62.5 MHZ | 47.0 | 24.0 | 0.3 |
| 100.0 MHZ | 43.0 | 20.0 | 0.4 |
STANDARDS COMPLIANCE
* TIA 568 C.2
* ISO 11801
* UL Llisted
Competitive Advantage
- For price, our offer can be much more competitive than other
suppliers such as the trading company, as we have our own factory.
- For quality, our superior raw material, skilled production team,
advanced equipment and mature quality control system could assure
you of that we could offer the cable with high and consistent
quality.
- For production capacity, we could produce 30 million meters cable
monthly, which will assure you of prompt delivery of the goods.
- Certificates: ISO, CE, CCC,ETL, RoHS ,ANATEL & UL approval.
